Width: 210 mm - 8,26 in
Inlet: 3/8" Bsp M
Outlet: 2 × 1/8" Npt F
Weight: 759 gr. - 26.77 oz.
Made of nickel-plated brass, with stainless steel arms.
Rotating front gaskets in high resistance ceramic material.
Axial balance force to minimize wear out 2 Stainless steel ball bearings.
Ball bearings protected against water leaks. High performance and long life span.
Rated Pressure
350 bar - 35 MPa - 5100 psi
Permissible Pressure
390 bar - 39 MPa - 5650 psi
Rated Flow Rate
40 l/min - 10.5 USGpm
Rated Temperature
120 °C - 250 °F
Max. working.Temp
90 °C - 195 °F
