23Hp V-twin Powerease Engine
$2,100.00
TITLE | SPECS |
---|---|
MODEL | POWEREASE R740D |
PART # | 85.575.270 |
CYLINDERS: | 2 CYLINDER V-TWIN |
ENGINE TYPE | AIR-COOLED 4-STROKE OHV |
DISPLACEMENT | 739CC |
STARTING SYSTEM | ELECTRIC |
IGNITION SYSTEM | TRANSISTORIZED MAGNETO |
COMPRESSION RATIO | 8.5:1 |
FUEL TANK CAPACITY | AUXILIARY |
FUEL | UNLEADED 86 OCTANE OR HIGHER |
CARBURETOR | HORIZONTAL TYPE BUTTERFLY VALVE |
LUBRICATION SYSTEM | FORCED SPLASH |
OIL CAPACITY | 1.5 LITRES (1.6 U.S. QTS) |
LOW OIL SHUTDOWN | YES |
SHAFT SIZE | 1" STRAIGHT KEYED |
KEY WAY SIZE | 1/4" X 2.2" |
SHAFT ROTATION | COUNTERCLOCKWISE |
NET TORQUE | 49 N*M/36.1 FT-LB @ 2,500 RPM |
NET POWER OUTPUT* | 26 HP (19.4 KW) @ 3,600 RPM |
PTO BOLT SIZE | 3/8-24 UNF |
BORE X STROKE | 88 mm x 64 mm |
AIR CLEANER | DUAL ELEMENT |
VALVE CLEARANCE | 0.06" INTAKE 0.08" OUT AKE |
DRY WEIGHT | 85 LBS |
DIMS (LxWxH) | 15" x 18" x 19" |
CHARGE COIL AMP | 15 AMP |
